Xhorse XDSKE0EN Smart Key Box Bluetooth Adapter

  • $89.99
    Unit price per
Shipping calculated at checkout.

Xhorse XDSKE0EN Smart Key Box Bluetooth Adapter

SMART KEY BOX is a newly designed tool by Xhorse, aiming to help users achieve a non-remote driving experience. By installing the tool into your car, your smartphone is able to work as an independent car key. Usually, it inherits all of the functions of your original remote, including lock, unlock, panic and trunk. Furthermore, keyless entry is also a function that can be performed on your smartphone.

Highlights for Xhorse Smart key box:

It adpots advanced RF technology and is suitable for the car with push start function.
Support add smart key for car

Support add or modify the keyless-enter function

Maximum of 6 mobile phones and 6 smart keys are supported by this device.

How to install Xhorse Smart Box Step by Step?

1, Take out the original remote control, solder the cable according to the soldering diagram of the original remote control, pay attention to the direction.
2, Connect the RF antenna, LF antenna (connect any two interfaces of Lfantenna), and the original remote control to be transferred.
3, Find the Vbat wire and ground wire from fuse box, OBD interface or other locations
4, Find the ACC signal line (the original car radio, the line with electricity after the  navigation power onorthe instrument light on)
5, Connect the Vbat wire, ground wire and ACC wire of the power supply cable to the car
6, Setting DIP switch;
7, Bindings of remote control and mobile phone (refer to binding instruction);
8, Install complete;
9, After installed, take a key close to the car, test the automatic unlock and lock  function if you stay away (test other keys in the same way)
10, Test unlock, lock, trunk and car panic function after connecting with APP.

The installation process in a glance:

  • Solder Supplied Wires To The PCB Of An Xhorse Universal Remote
  • Program This Remote To The Vehicle
  • Connect The Smart Key Box To The Vehicle Through The OBD2 Connector

Package List:

1pc smart box
2pcs LF antenna
1pc RF antenna
1pc Power supply cable
1pc User manual
1pc Product quality certificate
